The 5-axis robot adds two parallel rotating axes based on the traditional three-axis parallel robot. One axis controls the horizontal rotation and the other axis controls the vertical rotation. The two intermediate axes are controlled by servo coupling, which has higher precision, faster speed and longer service life.

1. An additional pitching degree of freedom enables posture transitions from horizontal grasping to vertical placement. 2. With a standard cycle time of 0.3 seconds, it meets requirements for maximum speed and minimal footprint. 3. The specially designed rotational axis hinge effortlessly handles demands for high-intensity, high-frequency repetitive motions. 4. It is exceptionally well-suited for posture adjustment tasks such as bottle filling in the food and beverage industry, as well as oriented material insertion in daily chemical applications.
