The 5-axis robot adds two parallel rotating axes based on the traditional three-axis parallel robot. One axis controls the horizontal rotation and the other axis controls the vertical rotation. The two intermediate axes are controlled by servo coupling, which has higher precision, faster speed and longer service life.

1. It adds a pitching degree of freedom to enable posture changes from horizontal grasping to vertical placement. 2. With a standard cycle time of 0.3 seconds, it meets the requirements for both maximum speed and minimal footprint. 3. The specially designed rotational-axis hinge easily accommodates high-intensity and high-frequency repetitive motion needs. 4. It is highly suitable for posture adjustment applications such as bottle filling in the food and beverage industry, and oriented material insertion in the daily chemical sector.
